Juliana Joplin CC 29 – X0 AXS Reserve
The Joplin’s 29-inch wheels and lean frame float over washboard bumps with the same ease it devours jagged ledges. The geometry of a big travel trail bike blended with 130mm of travel in the front and 120mm in the rear, creating a capable climber that doesn’t flinch when roots get ragged and rocks start to roll. Let’s go fast. Let’s go far. Let’s go until your legs are ready to give up, and then go some more. Let’s make every second count. Let’s carve rides out of busy days and put those lines on the map on your done list.
Key Details:
- Carbon CC Frame
- FOX 34 Float Factory Fork
- FOX Float Factory Shock
- SRAM X0 Eagle AXS T-Type Drivetrain
- Reserve 30|SL Carbon Wheels
Specifications:
| Frame | |
|---|---|
| Material | Carbon CC |
| Suspension | |
| Fork | FOX 34 Float Factory, Grip X, 130mm |
| Shock | FOX Float Factory, 190×45 |
| Drivetrain | |
| Rear Derailleur | SRAM X0 Eagle AXS T-Type, 12spd |
| Crankset | SRAM X0 Eagle DUB T-Type Crankset, 32t |
| Cassette | SRAM X0 Eagle T-Type, 10-52t |
| Chain | SRAM X0 Eagle T-Type, Flattop, 12spd |
| Bottom Bracket | SRAM DUB 73mm MTB Wide BB |
| Brakes | |
| Brakes | SRAM Code Silver Stealth |
| Front Rotor | SRAM HS2 180mm |
| Rear Rotor | SRAM HS2 180mm |
| Cockpit | |
| Handlebars | Santa Cruz 20 Carbon Bar, 760mm |
| Stem | Burgtec Enduro MK3, 42mm |
| Headset | Cane Creek 40 IS Integrated Headset |
| Seatpost | OneUp Dropper Post, 31.6 |
| Saddle | Juliana Primiero -or- WTB Deva, Cromoly SL |
| Wheels | |
| Front Rim | Reserve 30|SL Carbon |
| Front Hub | DT Swiss 350, 15×110, 6-Bolt, 28h |
| Front Tire | Maxxis Forekaster 29″x2.4″WT, 3C, MaxxTerra, EXO |
| Rear Rim | Reserve 30|SL Carbon |
| Rear Hub | DT Swiss 350, 12×148, XD, 6-Bolt, 28h, DEG 90T |
| Rear Tire | Maxxis Forekaster 29″x2.4″WT, 3C, MaxxTerra, EXO |
| Specs | |
| Headset | Integrated (IS41/52) |
| Translation missing: en.products.product.specs.seat_post | 31.6mm |
| Seat Clamp Diameter | 36.4mm |
| Rear Brake Mount | PM 180mm |
| Bottom Bracket Shell | 73mm Threaded |
| Max Tire Clearance | 2.5″ |
| Max Chainring Size | 36t |
| Water Bottle Mounts | 1 |
| Shock Length | 190mm |
| Shock Stroke | 45mm |
| Shock Bushing Size Front | 30×8 |
| Shock Bushing Size Rear | 30×8 |
| Fork Offset | 44mm |
Sizing & Geometry:
